Wireless Security Camera System
(YD8208N/YD8204N-YD8201W-TY)

Automatic Wireless Connection, plug and play

1080P H.265+ 4ch or 8ch wireless network recorder and 4pcs or 8pcs 1080P wireless cameras

In open space without interfere transmission distance up to 800 meters

Insert professional surveillance Wireless board, with stronger anti-interfere ability

Support alarm push motion detection and alarm output(voice/email/ FTP etc.)

Support Android/Apple cell phone or pad by LAN & WAN visit and control

P2P IP PRO, fluent and fast remote access

Suit to homes, offices, small businesses & retail stores

Easy to Install, User-Friendly Operation

Wireless Security Camera System (YD8208N/YD8204N-YD8201W-TY)

Wireless Security Camera System
MODEL YD-8201W-TY
Camera Image sensor 1/2.9" 2.0M Pixel CMOS
Lens 4 mm, horizontal field of view: 75°
Min. Illumination Color:0.01Lux@(F1.2,AGC ON)
B/W:0.001Lux@(F1.2,AGC ON),0Lux @(IR led ON)
S / N ratio ≥39dB
Day & Night Day / Night / External control(IR Cut Filter)
White balance Auto/Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp
Wide dynamic range Digital Wide dynamic range
Digital noise Reduction  2DNR,3DNR
Max.Image Resolution 1920x1080@20fps
Image Resolution Main stream(1920x1080、1280×960、1280×720、720×576、640×480)
Bit rate CBR/VBR, bit rate:32Kbps~10Mbps variable
Privacy Zone Masking 4 privacy masks programmable
P2P Android、IOS
Protocols TCP/IP,HTTP, NTP,IGMP, DHCP,UDP,SMTP,RTP,RTSP,ARP,DDNS,DNS,P2P
Onvif Non- Support
Wireless Frequency:2.4G
Transmission distance :More than 800 meters with no obstacle, More than 30 meters if penetrate the wall,
The actual transmission distance according to the situation
Power 12VDC@0.12A
Dimensions 38x38x5mm
Video Compression H.265 Main Profile/H.264 Main Profile/M JPEG
Audio Compression G711,PCM
Working Temperature -30°C ~60°C, Humidity≤90%RH(Un support condensing)
Model YD-8208N-TY or  YD-8204N-TY
NVR Chips Hi3536D
Video compression H.265 High Profile/ H.264 Main Profile
Video output 720P60,XGA,1080P60
Video input(IP)  8*1080P/8*960P/8*720P  /   4*1080P/4*960P/4*720P
Audio compression G.711
Recording mode Manual/Alarm/Video Detection/Continuous
Local Playback 8*1080P  /  4*1080P
Backup mode Network backup, USB hard disk
Protocol TCP/IP,HTTP,DHCP,UDP,RTP,RTSP,FTP,NTP,SADP,P2P
Frequency 2.4G
Antenna Structure 2 × 2MIMO
Video output 1ch HDMI, 1ch VGA output
Audio I/O None
Alarm I/O None
Network interface 1*RJ45 10M/100M Adaptive Ethernet port
USB  2*USB 2.0 port
Hard disk 1 SATA(Up to 4TB)
Power supply DC +12V /2A
Humidity <80%
Work environment -20℃~50℃
Packing 4ch Color Box Size 315*175*275mm
G.W/Color Box 3.2KG
8ch Color Box Sizey 315*275*275mm
G.W/Carton 5.5KG
